  • 4.3-inch touch screen
  • Intergrated OLS＆OPM
  • Built-in RJ45
  • 9 Calibration Wavelengths Available
  • 5000mAh high capacity battery
Manufacturing

JILONG
Product Manual

c

c

Product Specifications

Key specifications at a glance—defining quality and performance through data.
OPM
wavelength range 850-1650 (nm)
Test Wavelength 850/1270/1300/1310/1490/1550/1577/1625/1650 (nm)
Power Test Range -70~+6 (dBm)
Uncertainty < (±0.2dB or ±5%)
Power Stability ±0.1dB
Resolution 0.01dB
User-independent calibration √
VLS
Wavelength(nm) 1310/1550
Spectral width (nm) ≤5
Output power (dBm) 1mW ±0.2mW
Output stability (dBm) ±0.05/15min, ±0.2/8h
Modulation frequency CW, 270Hz, 1kHz, 2kHz
Auto Power-Off Time 10min
General Parameters
Language English, Chinese, Spanish, French, Portuguese, Russian, Thai, Korean
Optical Fiber Port FC/UPC (SC/UPC Optional)
Display Screen 4.3-inch color LCD display screen
Port Charging Portx1, USB 2.0x1, RJ45x1
Working Temperature -10-50°C(0 to 40 °C for use with power, 0 to 35 °C battery charging)
Storage Temperature -20~ 60°C
Height 4000 m
Humidity 0 to 90% RH (20%-90% 739874 AC adapter, non-condensing)
Power Mode 100-240V AC,50/60Hz (AC adapter)
Battery 3.7V,5000mAh,≥18.5Wh
Lighting Light Intensity>15000mcd
Data Storage Memory: Each wavelength can store 100 pieces of data; External Storage: USB
Size 179 mm (W) × 112 mm (H) × 48 mm (D)
Weight 0.6 kg (Unit + Battery)

Note: All specifications are based on measurements with a new battery at 23°C ± 2°C
